Sr. No. |
Details of Materials |
Quantity |
1. |
Oven, inside chamber stainless steel with digital temperature controller, size 18 ” x 18 ” x 18 ” |
01 |
2. |
HS 14.05 Core cutter apparatus |
01 |
3. |
HS 10.05 Liquid limit apparatus. |
02 |
4. |
HS 10.30 Shrinkage Limit Apparatus. |
01 |
5. |
HS 14.20 Pycnometer |
06 |
6. |
HS 14.10 Sand pouring cylinder |
02 |
7. |
HS 18.535 Consolidation test apparatus Electronic Three Gang. |
01 |
8. |
HS 20.10 CBR Accessories & apparatus. |
01 |
9. |
HS 22.100 Vane shear apparatus, motorised. |
01 |
10. |
HS 24.15 direct Shear test apparatus 12 speed motorised complete with proving ring & dial gauge. |
01 |
11. |
HS 22.15 Unconfined compression apparatus ( motorised proving ring tipe) complete with proving ring and dial gauge. |
01 |
12. |
HS 26.35 Triaxial shear test apparatus option no. III. |
01 |
13. |
HS 32.35 Sieves, 200mm dia. Span brass frame, 4.75mm, 2.36mm, 1.18mm, 600 mic, 300 mic , 150mic, 75mic, lid & pan. |
02 |
14. |
HS 32.50 sieves, 450mm dia. G.I. Sheet frame, 100mm , 80mm,63mm,401mm,25mm,20mm,12.5mm, 4.75mm, 6.3mm, lid and pan. |
02 |
15. |
HS 31.15 Sieves shaker |
01 |
16. |
HS 34.15 Soil investigation auger. |
02 |
17. |
Permeability – HS 12.05 constant head. |
01 |
18. |
Permeability – HS 12.10 varying head. |
01 |
19. |
SPT Special HS 34.80 spilt spoon sampler, HS 34.100 Drop Hammer, HS 34.105 guide pipe Assembly, HS 34.110 Tripod stand. |
01 |
20. |
Hydrometer HOS Pipette 25 MI. |
01 |
21. |
Hydrometer Flask ( Glass Jar) |
01 |
22. |
HS 10.100 Proctor needle. |
01 |
23. |
HOS Weighing balance ( capacity 20 kg.), 1 gm. Readability, platform size 350 x 250 mm |
01 |
24. |
HOS Weighing balance ( Capacity – 500g) 0.01gm. |
01 |
25. |
HOS Bowles ( China bowl, 6” dia.) |
03 |
26. |
Shrinkage apparatus complete kit without mercury. |
01 |
27. |
Compaction test apparatus complete with 150mm dia. X 2250 cc volume mild steel mould with base plate & collar zink plated with rammer 4.89kg x 450mm controlled fall. |
01 |
28. |
Compaction test apparatus complete with 100mm dia. X 100cc volume with collar & base plate and 2.6 kg x 310mm controlled fall rammer made of m. s. zinc plated. |
01 |
Total Investment |
7,82,049/- |
 |
