CONCRETE TECHNOLOGY LABORATORY


<<< Back to Laboratory


Sr. No. Details of Materials Quantity
1. HC 37.10 Vicat ’s apparatus with dash pot 03
2. HC 37.60 Slump cone test apparatus 02
3. HC 37.65 Vee bee Constistometer. 01
4. HC 37.75 Compaction factor apparatus 01
5. HC 38.05 Le- Chatlier Mould 6
6. Cube mould with ISI Mark 15 x 15 x 15 cm 12
7. HC 42.10 cube mould with ISI Marks 70.6mm x 70.6mmX70.6mm. 12
8. HC 42.85 150mm x 300mm high, cast iron 12
9. Beam mould with as per IS: 10086 – 1982 HC 42.50
100 X 100 X 500 mm made of cast iron.
12
10. HC 42.55 150mm x 150mm x 700mm made of cast Iron. 12
11. HC 42.25- 1 Tamping bar 12
12. HC 40.25 std. Spatula 05
13. HC 40.30 Gauging trowel 05
14. HLM 592.301 compression testing machine with digital Readout unit, 200 Tonnes. 01
15. HA 50.20 Thickness gauge of C.A. 01
16. HA 50.25 Elongation gauge of C.A. 01
17. HA 50.40 Density basket 03
18. HC 46.20 Concrete test hammer 01
19. Weighing balance HOS. Electronic balance 60 kg.
Capacity 1 gm readability, platform size 235 x 335 mm
01
20. HC 42.140 Table Vibrator 01
21. Concrete mixer, motorised, 1 craft capacity. 01
22. HOS Water bath 01
23. HS 32.45 sieves, 300mm dia. G.I. sheet Frame 100mm, 80mm, 63mm, 40mm, 25mm, 20mm, 12.5mm, 4.75mm, 6.3mm, lid & pan. 02
24. HS 32.35 Sieves, 200mm dia. Span brass frame 4.75mm, 2.36mm, 600mic, 300mic, 150mic, 75mic, lid & pan. 01
25. GI Power coated sieves 45 cm dia. 10mm. 01
26. Brass sieves 20cm dia. 1.18m 01
27. Cube Mould 150 mm 12
28 FLOW TABLE (MOTORISED) 01
29 L-BOX FOR SELF COMPACTING CONCRETE. M.S. 01
30 U-BOX FOR SELF COMPACTING CONCRETE. M.S. 01
31 V-FUNNEL FOR SELF COMPACTING CONCRETE - M.S. 01
32 J RING FOR SELF COMPACTING CONCRETE. M.S. 01
33 ULTRASONIC PULSE VELOCITY METER. CONTROLS MAKE 01
Total Investment   5,42,912/-
